Product Details
Specifications
Electrical Specifications
Connected Load @ 240V: 6
Voltage Rating: 120/240V 60Hz 25A or 120/230V 60Hz 24A
Connection Location: Rear
Connected Load @ 120V: 0.835
Amps @ 120 Volts: 9
Amps @ 240 Volts: 25
Accessories
Luxury-Glide® Pedestal with Spacious Storage Drawer: Optional order item no. EPWD257UIW (Island White)
Dryer Stacking Kit: Optional order item no. STACKIT7X
LP Conversion Kit: Optional order item no. PCK4200
Drying Rack: Optional order item no. A04840701
Dryer: Cycles
Active Wear: No
Touch Up: No
Fast Dry: No
Dry Cycles: 5
Delicate: Yes
Bulky/Bedding: No
Allergen: No
My Favorite: No
Perfect SteamTM: No
Normal: Yes
Heavy Duty: Yes
Timed Dry: Auto / 60 /30
Casual: Yes
Towels: Yes
Mixed Load: No
General Specifications
Sound Package: Luxury-QuietTM
Motor HP: Variable
Reconditioned: No
PROP 65 Label: No
Power Cord Included: No
Gas Connection Location: N/A
Style: Full-Size Model
Shipping Weight (lbs): 140
Leveling Legs: 4
Controls
Display Type: LED
Control Lock: Yes
Control Location: Front
Control Type: LED display with capacitive touch controls
Delay Start - hours: No
Exterior Dimensions
Depth: 31-1/2"
Height (w/15" Pedestal): 53"
Height(w/o 15" Pedestal): 38"
Depth(w/ 90° Door Open): 53.5"
Width: 27"
Height: 38"
Exterior Specifications
Door Latch: Pull Latch
Lens Ring: White
Reversible Door: Yes
Door Design: Pull to Open
Certifications & Approvals
ENERGY STAR® Certified: Yes
CSA Listed: Yes
ETL Listed: No
UL Listed: 1-UL Listed
Agency Approval(All Brands): UL/CSA
NSF® Certified: No
Dryer Specifications
Air Flow (CFM): 220
Dryer: Specialty Cycles
Jeans: No
Air Clean: No
Kids Wear: No
Pet Beds: No
Warm Up: No
Wool: No
Active Wear: No
Stuffed Animals: No
Fast Steam: No
Comforter: No
Dryer: Options
Temperature Selections: 3
Line Dry: No
Anti Static: No
Tumble System: Gentle TumbleTM
Eco: Yes
Timed Dry Selections: 3 selections
Add Steam: No
Auto Dry System: No
End-of-Cycle Chime: Yes
Installation Type
Stacked(Above Washer): Yes
Under Counter: Yes (Side-by-Side units in under-counter installation require custom-built countertop and/or cabinetry)
Hidden (In Closet): Yes
Pedestal: Yes
Dryer Specifications
Individual Custom Options: 0
Moisture Sensor: Yes
Drum Material: Painted Steel
Tumble Speed (RPM): 50
Heating Element (BTU/HR): N/A
Interior Lighting: No
Drying Rack: No
Dry System: No
Capacities
Total Capacity - Cu. Ft.: 8.0 Cu. Ft.
Specifications
Part No./SKU |
EFDE317TIW |
